Camera |
Image Sensor | 1/1.8'' CMOS |
Image Resolution | 2688 (H) × 1520 (V) (OSD black background is not calculated in the pixels) |
Shutter Mode | Single shutter |
Electronic Shutter Speed | Auto/Manual 1/50 s–1/100,000 s |
Noise Reduction | 3D NR |
S/N Ratio | > 56 dB |
WDR | 140 dB |
Min. Illumination | 0.0001lux |
Day/Night | Supports ICR auto switch: IR cut-off filter (IRCF) with the polarizing filter is used during the daytime, and switches to the IR transmitting filter at night |
Illuminator |
Illuminator Number | 4 illuminators (850 nm LED illuminators, adjustable brightness) |
IR Light | Yes |
Illumination Distance | 23 m–30 m (75.46 ft–98.43 ft) (adjustable brightness) |
Lane Coverage | 1–2 lanes |
Lens |
Lens | Motorized vari-focal |
Focal Length | 10 mm–50 mm |
Max. Aperture | Max. F1.33 |
Field of View | Horizontal: 9.4°–40.8°
Vertical: 5.4°–22.9°
Diagonal: 10.7°–46.9° |
Exposure Mode | Auto; Manual (Select from shutter values or customize shutter range) |
Function |
Trigger Mode | Video trigger/Radar trigger |
Speed Detection Range | 0 km/h–180 km/h |
OSD Overlay | Time, address, device SN, lane No., plate number, plate color, vehicle logo, vehicle type, vehicle color, vehicle size, vehicle speed, country/region, event (violation name), and motorcycle attributes (type, number of people, and helmet) |
Alarm Event | Storage full; storage error; external alarm; no storage card; license plate blocklist; illegal access; network disconnection; IP conflict |
Automatic Network Replenishment (ANR) | Platform and FTP (TF card is required) |
Auto Registration | Yes |
Intelligence |
Target Detection | Motor vehicle; motorcycle |
ANPR | Adopts developed algorithms to recognize license plate numbers and letters |
Vehicle Type Recognition | Vehicle head: SUV, Large bus, sedan, light truck, pickup, heavy truck, medium truck, van, medium bus, MPV Vehicle tail: SUV, large bus, sedan, light truck, pickup, heavy truck, medium truck, van |
Vehicle Color Recognition | White, pink, black, red, yellow, gray, blue, green, dark orange, purple, brown, and silver gray (color recognition is not supported during nighttime) |
Vehicle Brand/Logo Recognition | Acura; Alfaromeo; Ashokleyland; Astonmartin; Audi; Baic; Bently; Benz; BMW; Buick; BYD; Cadillac; Chery; Chevrolet; Chrysler; Citroen; Dacia; Daihatsu; Datsun; Dodge; DS; Ferrari; Fiat; Force; Ford; Foton; Geely; GMC; Greatwall; Hino; Honda; Hyundai; Infiniti; Isuzu; Iveco; Jac; Jaguar; Jeep; Kia; Kinglong; Land; Lexus; Lifan; Lincoln; Mahindra; MAN; Maserati; Mazda; Mercury; MG; Mini; Mitsubishi; Nissan; Opel; Peugeot; Porsche; Renault; Rollsroyce; Saab; Scania; Seat; Skoda; Smart; Subaru; Suzuki; Tata; Tesla; Toyota; UD; Volkswagen; Volvo |
Motor Vehicle Violation Capture | Speeding; driving slow; wrong-way driving; illegal lane change |
Motorcycle Violation Capture | Captures traffic violations including carrying passenger, not wearing helmet, and wrong-way driving |
Traffic Flow Detection | Statistics on vehicle flow, average speed, vehicle type, lane occupancy, average time headway, average queue length, and road status |
Traffic Event | Motor vehicle illegal stopping on the roadway; traffic congestion |
Video |
Video Compression | H.265; H.264M; H.264H; MJPEG |
Video Resolution | 4M (2688 × 1520); 1080p (1920 × 1080); UXGA (1600 × 1200); 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288) |
Video Frame Rate | Max. 30 fps; main stream (2688 × 1520@25 fps), sub stream (1600 × 1200@25 fps) |
Video Bit Rate | H.264: 32 kbps–32767 kbps
H.265: 32 kbps–32767 kbps
MJPEG: 512 kbps–32767 kbps |
Bit Rate Control | CBR; VBR |
White Balance | Auto; Manual; Outdoor; Natural; Street Lamp; Partial white balance |
Edge Enhancement | Yes |
HLC | Yes |
BLC | Yes |
Bad Pixel Correction | Yes |
Gain Range | 0–100 |
Image |
Composite Image | Supports combining up to 3 source images, and 1 close-up image into a composite image |
Image Resolution | 2688 (H) × 1520 (V) (OSD black background is not calculated in the pixels) |
Image Encoding Format | JPEG |
Image Tampering Prevention | Verifies watermarks in videos and images |
Network |
Network Port | 1 × RJ-45 Ethernet port, 10/100/1000 M network transmission |
SDK and API | Yes |
Security | Authorized username and password, MAC address binding, HTTPS encryption, and network access control |
Protocol | IPv4; IPv6; HTTP; TCP; IP; UDP; NTP; DHCP |
Interoperability | ONVIF (Profile S/Profile G/Profile T) |
Browser | Microsoft Edge IE: IE9–IE11 Chrome: Chrome 41 and earlier Firefox: Firefox 49 and earlier For Win 10 users, run the browser as administrator |
Positioning | GPS |
Time Synchronization | NTP; GPS |
Port |
Storage | 1, supports maximum 512 GB TF card local storage |
RS-485 | 2, connects to devices such as radars |
RS-232 | 2, con is used for serial debugging and R T G is for connecting to radars |
Audio Input | 1 channel |
Audio output | 1 channel |
Alarm Input | 3 channel |
Alarm Output | 2 channels. 2 for relay |
General |
Power Supply | 12–36 VDC, PoE |
Power Consumption | ≤ 13 W |
Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
Storage Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
Operating Humidity | 10%-90% (RH) |
Storage Humidity | 0%-90% (RH) |
Protection | IP67, IK10, defog |
Certifications | CE EMC: EN55032; EN55035; IEC61000-3-2; IEC61000-3-3 CE LVD: EN62368-1; IEC62471 CE RED: EN301511; EN301489-1/7; EN62311; EN50360 |
Product Dimensions | 466.4 mm × 135.8 mm × 134.1 mm (18.36'' × 5.35'' × 5.28'') (L × W × H) |
Net Weight | 3.9 kg (8.59 lb) |
Gross Weight | 4.8 kg (10.58 lb) |
Installation | Installs with universal mounting brackets, or as a side-mount with mounting brackets |
