Camera |
Image Sensor | 1/2.8" CMOS |
Pixel | 8 MP |
Max. Resolution | 3840 (H) × 2160 (V) |
ROM | 4 GB |
RAM | 1 GB |
Electronic Shutter Speed | 1/1 s–1/30,000 s |
Scanning System | Progressive |
Min. Illumination | Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux@F1.6 (IR light on) |
Illumination Distance | 100 m (328.08 ft) (IR) |
Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off |
Illuminator Number | 4 (IR) |
Lens |
Focal Length | 5 mm–125 mm |
Max. Aperture | F1.6–F3.6 |
Field of View | H: 53.1°–3.4°; V: 30.4°–1.9°; D: 59.3°–3.9° |
Optical Zoom | 25× |
Focus Control | Auto; semi-auto; manual |
Close Focus Distance | 0.1 m–1.5 m (0.33 ft–4.92 ft) |
Iris Control | Auto; manual |
DORI Distance | Detect | Observe | Recognize | Identify |
2161.4 m (7091.21 ft) | 864.6 m (2836.61 ft) | 432.3 m (1418.30 ft) | 216.1 m (708.99 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
PTZ |
Pan/Tilt Range | Pan: 0° to 360° endless
Tilt: –15° to +90°, auto flip 180° |
Manual Control Speed | Pan: 0.1°–200°/s
Tilt: 0.1°–120°/s |
Preset Speed | Pan: 240°/s
Tilt: 200°/s |
Preset | 300 |
Tour | 8 (up to 32 presets per tour) |
Pattern | 5 |
Scan | 5 |
Power-off Memory | Yes |
Idle Motion | Pattern; Preset; Scan; Tour |
PTZ Protocol | DH-SD Pelco-P/D(Auto recognition) |
Intelligence |
IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first
Supports up to 5 face databases; registers person one by one or in batches; sets face similarity; compares faces with 10,000 faces. |
SMD | SMD 4.0 |
Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
Video |
Video Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+ |
Streaming Capability | 3 streams |
Resolution | 4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA(640×480);CIF (352 × 288/352 × 240) |
Video Frame Rate | Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/VGA/CIF (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/CIF (1–25/30 fps) |
Bit Rate Control | CBR/VBR |
Video Bit Rate | H.264: 3,328 kbps–8,192 kbps
H.265: 1,280 kbps–8,192 kbps |
Day/Night | Auto (ICR)/Color/B/W |
BLC | Yes |
WDR | DWDR |
HLC | Yes |
White Balance | Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp |
Gain Control | Auto; manual |
Noise Reduction | 2D NR; 3D NR |
Motion Detection | Yes |
Region of Interest (RoI) | Yes |
Defog | Electronic |
Digital Zoom | 16× |
Image Rotation | 180° |
Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view |
S/N Ratio | ≥ 55 dB |
Audio |
Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
Network |
Network Port | 1 × RJ-45 (10/100 Base-T) |
Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP |
Interoperability | RTMP; CGI; SDK; ONVIF (Profile S&G&T); P2P |
Streaming Method | Unicast/Multicast |
User/Host | 20 (total bandwidth: 64 M) |
Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
Browser | IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
iOS 10 and later versions |
Management Software | DSS Pro; DMSS |
Mobile Client | iOS; Android |
Certification | |
Certifications | CE-EMC: EN 55032; EN 61000-3-3; EN 61000-3-2; EN 50130-4; EN 55035 CE-LVD: EN 62368-1 FCC: 47 CFR FCC Part15, Subpart B, NSI C63.4 UL: UL62368-1 |
Port |
Audio Input | 1 channel |
Audio Output | 1 channel |
Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital input |
Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
Alarm I/O | 2/1 |
Audio I/O | 1/1 |
Power |
Power Supply | 12 VDC/3A±10%
PoE (802.3at) |
Power Consumption | Basic: 9.8 W
Max.: 20 W (Illuminator + alarm + PTZ) |
Environment |
Operating Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
Operating Humidity | ≤ 95% |
Storage Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
Storage Humidity | ≤ 95% |
Protection | IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection |
Structure |
Product Dimensions | 270.4 mm × Φ160 mm (10.65" × Φ6.30") |
Net Weight | 2.4 kg (5.29 lb) |
Gross Weight | 3.9 kg (8.60 lb) |
