System |
Main Processor | Industrial-grade processor |
Operating System | Embedded Linux |
Operating Interface | Web, Local GUI |
AI |
AI by Recorder | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; AcuPick |
AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection; AcuPick |
AcuPick Performance of AI by Recorder (Number of Channels) | 4 channels |
AcuPick Performance of AI by Camera (Number of Channels) | All channels (32 targets/s) |
Perimeter Protection |
Perimeter Performance AI by Recorder (Number of Channels) | 8 channels, 10 IVS rules for each channel |
Perimeter Performance of AI by Camera (Number of Channels) | All channels (32 targets/s) |
Face Detection |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
Face Detection Performance of AI by Recorder (Number of Channels) | 4 channels (up to 12 face images/s each channel) |
Face Detection Performance of AI by Camera (Number of Channels) | All channels (32 targets/s) |
Face Recognition |
Face Database Capacity | Up to 20 face databases with 30,000 images, with a total capacity of 3.75 GB. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
Face Recognition Performance of AI by Recorder (Number of Channels) | 1. 24-channel FD (by camera) + FR (by recorder), image stream: 24 face images/s
2. 4-channe FD (by recorder) + FR (by recorder), video stream: 24 face images/s |
Face Recognition Performance of AI by Camera (Number of Channels) | All channels (32 targets/s) |
SMD |
SMD Plus by Recorder | 16 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
SMD by Camera | All channels (64 targets/s) |
Video Metadata |
Metadata Performance of AI by Recorder (Number of Channels) | 4 channels, 22 attributes extraction. |
Metadata Performance of AI by Camera (Number of Channels) | All channels (16 targets/s) |
People Attributes | Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella |
Motor Vehicle Attributes | License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location |
Non-motor Vehicle Attributes | Vehicle model, vehicle color, number of persons, helmet |
Vehicle License Plate Comparison |
ANPR by Camera (Number of Channels) | All channels (8 targets/s) |
License Plate Database Capacity | 1. Create up to 20,000 plate numbers.
2. Blocklist and allowlist |
Audio and Video |
Access Channel | 32 channels |
Network Bandwidth | AI disabled: 448 Mbps incoming, 448 Mbps recording and 448 Mbps outgoing
AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing |
Resolution | 32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF |
Decoding Capability | AI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 5-channel 16 MP@30 fps; 6-channel 12 MP@30 fps; 10-channel 8 MP@30 fps; 13-channel 6 MP@30 fps; 16-channel 5 MP@30 fps; 20-channel 4 MP@30 fps; 32-channel 1080p@30 fps
AI enabled: 1-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 10-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps |
Video Output | 2 VGA, 2 HDMI
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
HDMI: 7680×4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Heterogeneous video source output for HDMI1 and HDMI2
Simultaneous video source output for VGA1 and HDMI1
Simultaneous video source output for VGA2 and HDMI2 |
Multi-screen Display | Main Screen: 1/4/8/9/16/25/36
Sub Screen: 1/4/8/9/16 |
Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
Compression Standard |
Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
Audio Compression | G.711a; G.711u; PCM; G726 |
Network |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.); iSCSI |
Mobile Phone Access | iOS; Android |
Interoperability | ONVIF 25.06 (Profile T; Profile S; Profile G; Profile M); CGI; SDK |
Browser | Chrome; IE; Safari; Edge; Firefox |
Network Mode | Multi-address; load balance; fault tolerance; link aggregation |
Recording Playback |
Multi-channel Playback | Up to 16 channels |
Record Mode | General, motion detection; intelligent; alarm; POS |
Backup Method | USB device and network |
Playback Mode | Instant playback, general playback, event playback, target Video, video clip, tag playback, smart playback (face and motion detection) |
Storage |
Disk Group | Yes |
Alarm |
General Alarm | Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm |
Anomaly Alarm | Error (no disk; disk error; low space; low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict; abnormal fan speed); video loss; video tampering; camera offline; audio detection |
Intelligent Alarm | Face detection; perimeter protection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map; PPE detection; smart object detection; smart sound detection |
Alarm Linkage | Record; snapshot (panoramic); local alarm output; IPC external alarm output; audio; buzzer; log, preset; email |
Port |
Audio Input | 1-channel RCA |
Audio Output | 2-channel RCA |
Alarm Input | 16 channels |
Alarm Output | 6 channels (1-channel 12 V 1 A output） |
Disk Interface | 4 SATA ports, each disk can contain up to 20TB. This limit varies depending on the environment temperature. |
eSATA | 1 |
RS-232 | 1 |
RS-485 | 1 |
USB | 3 (1 front USB 2.0 port, 2 rear USB 3.0 port) |
HDMI | 2 |
VGA | 2 |
Network Port | 2 (10/100/1000 Mbps Ethernet port, RJ-45) |
General |
Power Supply | 100–240 VAC, 50/60 Hz |
Power Consumption | Total output of NVR is ≤ 13 W (without HDD) |
Net Weight | 4.27 kg (9.41 lb) |
Gross Weight | 6.30 kg (13.89 lb) |
Product Dimensions | 440.0 mm × 415.6 mm × 76.0 mm (17.32" × 16.36" × 2.99") (W × D × H) |
Packaging Dimensions | 529.0 mm × 499.0 mm × 211.0 mm (20.83" × 19.65" × 8.31") (W × D × H) |
Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
Operating Humidity | 10%–93% (RH), non-condensing |
Certifications | CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014 |
