System |
Main Processor | Industrial-grade processor |
Operating System | Embedded Linux |
Operating Interface | Web, Local GUI |
AI |
AI by Recorder | Face detection; face recognition; perimeter protection; and SMD |
AI by Camera | Face detection; face recognition; perimeter protection; SMD; ANPR; people counting; stereo analysis; heat map |
Perimeter Protection |
Perimeter Performance AI by Recorder (Number of Channels) | 2 channels, 10 IVS rules for each channel |
Perimeter Performance of AI by Camera (Number of Channels) | All channels (8 targets/s) |
Face Detection |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
Face Detection Performance of AI by Recorder (Number of Channels) | 1 channel (up to 12 face images/s each channel) |
Face Detection Performance of AI by Camera (Number of Channels) | All channels (8 targets/s) |
Face Recognition |
Face Database Capacity | Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
Face Recognition Performance of AI by Recorder (Number of Channels) | 4-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s
1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
Face Recognition Performance of AI by Camera (Number of Channels) | All channels (8 targets/s) |
SMD Plus |
SMD Plus by Recorder | 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
SMD by Camera | All channels (16 targets/s) |
Audio and Video |
Access Channel | 4 channels |
Network Bandwidth | 80 Mbps incoming, 80 Mbps recording and 80 Mbps outgoing |
Resolution | 16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF |
Decoding Capability | AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps
AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 3-channel 6 MP@30 fps; 4-channel 5 MP@30 fps |
Video Output | 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. |
Multi-screen Display | 1st Screen: 1/4
2nd Screen: 1/4 |
Third-party Camera Access | Panasonic, Sony, Hanwha, Axis, Pelco, Arecont, ONVIF, Canon |
Compression Standard |
Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
Audio Compression | G.711a; G.711u; PCM; G726 |
Network |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera, DVR, NVS, etc.); P2P; Auto Registration |
Mobile Phone Access | iOS; Android |
Interoperability | ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK |
Browser | Chrome; IE9 and later; Firefox |
Recording Playback |
Multi-channel Playback | Up to 4 channels |
Record Mode | General, motion detection; intelligent; alarm |
Backup Method | USB device and network |
Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback |
Alarm |
General Alarm | Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
Anomaly Alarm | Error (no disk; disk error; low space; low quota space; abnormal disk health; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline; audio detection |
Intelligent Alarm | Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
Alarm Linkage | Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
Port |
Audio Input | 1-channel RCA |
Audio Output | 1-channel RCA |
Disk Interface | 1 SATA port, up to 20 TB.The maximum HDD capacity varies with environment temperature. |
USB | 2 (2 rear USB 2.0 ports) |
HDMI | 1 |
VGA | 1 |
Network Port | 1 (10/100 Mbps Ethernet port, RJ-45) |
PoE Port | 4 ports, 10/100 Mbps, IEEE 802.3 af/at |
General |
Power Supply | 53 VDC, 1.226 A |
Power Consumption | < 10 W (without HDD)
Total maximum output power of PoE is 45 W, the maximum output power of a single port is 25.5 W |
Net Weight | 0.50 kg (1.10 lb) |
Gross Weight | 1.38 kg (3.04 lb) |
Product Dimensions | 204.6 mm × 206.4 mm × 45.6 mm (8.06" × 8.12" × 1.80") (W × D × H) |
Packaging Dimensions | 364 mm × 96 mm × 261 mm (14.33" × 3.78" × 10.26") (W × L × H) |
Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
Operating Humidity | 10%–93% (RH), non-condensing |
Certifications | FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014 |
